Page 46: Herringbone brick pattern

46
D. Service Parts
Service Parts
09/08
Service Parts Diagram
A36R, A36RH
Part number list on following page.
Tr
aditional Brick Pattern
Accelerator W
oodburning Fireplaces
Herringbone Brick Pattern
Beginning Manufacturing Date: June 1998
Ending Manufacturing Date:
Active
1
2
3
4
5
8
9
7
6
8
8
6
7
Service Parts
09/08
Service Parts List
Beginning Manufacturing Date: June 1998
Ending Manufacturing Date:
Active
IMPOR
TANT
: THIS IS DA
TED INFORMA
TION. When requesting service or replacement
parts for your appliance please provide model number and serial number
. All parts listed
in this manual may be ordered from an authorized dealer
.
Stocked
at Depot
ITEM
D
ESCRIPTION
COMMENTS
P
A
RT NUMBER
1
S
tarter Section
22069B
Y
2
Top Standof
f
Qty 4 req.
4044-1
11
3
D
rywall Flange
29238
4
Hearth Filler
30331
5G
ra
te
GR18
Y
Grate Clip
Qty 2 req.
28062
Tr
aditional Refractory (A36R)
6
Hearth Refractory
Pre W
eek 34/98
29244
W
eek 34/98 thru SN#
AK652474
29993
Post SN#
AK652474
4010-017
7
B
ack Refractory
Pre W
eek 34/98
29245
W
eek 34/98 thru SN#
AK652474
29992
Post SN#
AK652474
4010-059
8
S
ide Refractory (Left/right)
Pre SN#
AK652474
28393
Post SN#
AK652474
4010-058
Herringbone Refractory (A36RH)
6
Hearth Refractory
4010-017
7
B
ack Refractory
Pre SN#
AK652474
4010-012
Post SN#
AK652474
4010-063
8
Left Hand Refractory
Pre SN#
AK652474
4010-010
Post SN#
AK652474
4010-061
9
Right Hand Refractory
Pre SN#
AK652474
4010-009
Post SN#
AK652474
4010-062
Damper Assembly
30528
Damper W
eight
19785A
Damper Blade
30558
Door Pivot Clip
Qty 2 req.
31527
Firescreen
Assembly
Qty 2 req.
26053
Y
Firescreen Handle
1 ea.
4021-150
Firescreen Rod
Q
ty 2 req.
12052
Y
Nailing Flange
Qty 4 req.
31
190
Outside Air
Kit
AK22
Refractory Retainer
11847
Smoke Diverter
30559
Strip Protector
Qty 2 req.
18320
Smoke Shield
31
191
Upper Door
T
rack
15425
Installation Instructions & Owner's Manual
28376
A36R, A36RH
