Please make sure all parts listed below are included before proceeding with the installation.
A. Dry‐wall anchor B. 1.77” L‐Bracket C. 3.54” L‐Bracket D. Y‐Bracket E. M5 Screw F. Wood Screw
G. Fix Plate H. Center Support Bar I. Support Joiner J. Elbow Joint
K. Butterfly Screw L. Tension Rods
M. Vertical Upright Frame
N. Horizontal Curved Frame
O. Screen Material
Parts List for the Lunette Series
