Model numbers parts list curve235, Dimensions of diagram on page 9 – Elite Screens 052611AS User Manual
Page 11

11
Rev.052611‐AS
www.elitescreens.com
85w
96w
103w
115w
125w
138w
147w
158w
Horizontal Curved Frame
2
2
2
2
2
2
2
2
Upright Vertical Frame
2
2
2
2
2
2
2
2
Elbow Joint
4
4
4
4
4
4
4
4
M5*15 Assembly Screw
9
9
9
9
9
9
9
9
Screen Material
1
1
1
1
1
1
1
1
Top/Bottom Tension Rod
2
2
2
2
2
2
2
2
Side Tension Rod
2
2
2
2
2
2
2
2
Center Support Bar
1
1
1
1
2
2
2
2
Support Joiner
2
2
2
2
4
4
4
4
Fix Plate
44
52
52
56
62
66
68
72
Dry‐wall anchor
7
7
7
7
9
9
9
9
M5*45 Wood Screw
7
7
7
7
9
9
9
9
1.77" L‐Bracket
4
4
4
4
2
2
2
2
3.54" L‐Bracket
0
0
0
0
2
2
2
2
Y‐Bracket
1
1
1
1
1
1
1
1
Butterfly Screw
5
5
5
5
5
5
5
5
Model
Number
View
Width
(A1)
View
Height
(A2)
Overall
Width
(B1)
Overall
Height
(B2)
Frame
Height
(C)
Distance
(D)
Distance
(E)
85w
78.19”
(1986)
33.28”
(845)
85.28”
(2166)
40.35”
(1025)
3.39”
(86)
39.96”
(1050)
39.96”
(1050)
96w
88.35”
(2244)
37.56”
(954)
95.43”
(2424)
44.65”
(1134)
3.86”
(98)
45.28”
(1150)
45.28”
(1150)
103w
94.77”
(2407)
40.31”
(1024)
101.85”
(2587)
47.40”
(1204)
4.17”
(106)
47.24”
(1200)
47.24”
(1200)
115w
105.83”
(2688)
45.00”
(1143)
112.90”
(2868)
52.09”
(1323)
4.80”
(122)
51.18”
(1300)
51.18”
(1300)
125w
115.00”
(2921)
48.90”
(1242)
122.09”
(3101)
55.98”
(1422)
5.35”
(136)
59.06”
(1500)
59.06”
(1500)
138w
126.97”
(3225)
53.98”
(1371)
134.06”
(3405)
61.06”
(1511)
6.22”
(158)
62.99”
(1600)
62.99”
(1600)
147w
135.24”
(3435)
57.52”
(1461)
142.32”
(3615)
64.6”
(1641)
6.81”
(173)
66.93”
(1700)
66.93”
(1700)
158w
145.40”
(3693)
61.81”
(1570)
152.48”
(3873)
68.90”
(1750)
7.56”
(192)
68.90”
(1750)
68.90”
(1750)
Measurement dimensions are intended as a reference only and subject to change without notice. Note: Data Error may be ±1"
Unit: (mm)
Model Numbers Parts List Curve235-
Model Number
Part Name
Dimensions of Diagram on page 9
