30
APPENDIX A
Specifications :
Product Name BT-0260 Printer Combo Adapter
Model Name BT-0260
Certification FCC, CE, BQB
Standard Bluetooth v1.1
Frequency Band 2.4~2.4835GHz unlicensed ISM band
Spread Spectrum FHSS (Frequency Hopping Spread Spectrum)
Services Supported SPP and HCRP print services
Data Rate 1 Mbps
RF Output Power Class 1; 13 dBm typical
Antenna Embedded PCB antenna
Working Distance Up to 100 meters in free space
Sensitivity <-88dBm at < 0.1% BER
Input Power 7.5V DC
I/O Interface USB, IEEE-1284
LED Indicators Power / Bluetooth active /Printing active
Operation Temperature 0 o C ~ + 60 o C
Storage Temperature -10 o C ~ +70 o C
Humidity 5 ~ 90% non-condensing
Size 81 (L) x 54(W) x 21(H) mm
