EPSON ActionNote 650
Serial
External
keyboard /
mouse
Keyboard
Trackball
Mass Storage
Hard disk drive
RS-232C, programmable, asynchronous, LCD Indicator The ActionNote 650 has the indicators
9-pin, D-sub male connector Panel shown in the table below
Auto-sensing, 6-pin, mini-DIN connector
for a PS/2-type external keyboard,
keypad, mouse, or other pointing device
Icon
Caps Lock
Meaning
Caps Lock is on.
85 / 86 keys; 101/102-key keyboard
compatible; embedded keypad; support
for hot key commands
Num Lock Num Lock is on.
Scroll Lock Scroll Lock is on.
Built-in 16 mm, PS/2 compatible trackball
with two buttons
Keypad Lock The embedded keypad
is locked.
One internal 2.5 inch long by .5 to .75 inch
(12.5 mm to 19 mm) high IDE hard disk
drive; SCU automatically detects standard
IDE drive types
The following table shows the
characteristics for the Toshiba
MK1724FCV drive.
Capacity 262MB Sectors 38
Heads 16
Cylinders 842
Diskette drive
System
Configuration
Utility
Software
LCD Screen
One internal, 3.5-inch, low power
consumption, diskette drive; 720KB or
1.44MB format
Stored in ROM; accessible by pressing
Ctrl Alt
S at system startup or at MS-DOS
prompt; includes power management
features
Latest versions of MS-DOS and Microsoft
Windows; Borland SideKick for Windows;
ClarisWorks for Windows; trial versions of
CompuServe WinCIM, America Online,
and OAG FlightDisk; PCMCIA services,
drivers, and utilities; on-line Windows
and other manuals; video drivers and
utilities for Microsoft Windows; power
management utilities; all installed on the
hard disk drive
Monochrome: 9.5-inch diagonal, 64 gray
shades, 640 x 480, backlit
Dual-scan STN color: 10.3-inch diagonal,
640 x 480 x 256 colors, backlit
Power Sources
AC adapter
Hard Disk
Activity
Diskette Drive
Activity
PCMCIA
Card Activity
Battery Status
Battery
Charging
AC Power
The computer is
accessing the hard disk
drive.
The computer is
accessing the diskette
drive.
The computer is
accessing a PCMCIA
card.
The system is in
suspend mode
Shows battery charge
status by displaying
from zero to four vertical
bars inside the battery
symbol.
The AC adapter is
charging the battery.
The computer is running
on AC power rather
than the battery.
Battery Rechargeable, 12 Volt, 2.6Ah NiMH
battery; current regulation and automatic
charge stop by thermistor
Caution
Use only the adapters and replacement batteries designed
for use with the ActionNote 650 series (AC adapter model
number TSA3 and battery model number 10HR-4/3AU).
AN650-2 10/25/94
