MagTek Device Drivers for Windows
100
Property Access Description
offline_enc R/W Set to
1
to enable encode capability in standalone mode with
keyboard;
0
prevents standalone encoding (MT-95).
oper_tout R/W Operational timeout in seconds (15-255). (IntelliPIN)
pin_blk_fmt R/W PIN block format (IntelliPIN):
ansi
(ANSI 9.8) or
ibm
(IBM 3624)
pinfilldig R/W PIN fill digit (0..9, A..F) when
pin_blk_fmt
is
ibm
(IntelliPIN)
port_name R Indicates the virtual port number (e.g., COM6) derived from the
friendly port name.
pwroffdelay R/W Power off time delay in minutes (5-255). (IntelliPIN)
s_down_tout R/W Shutdown timeout in hours (1-31). Set to
0
to disable. (IntelliPIN)
track1ss
track2ss
track2ss R
R
R Indicates Start Sentinel on Track 1 as received from the device.
Indicates Start Sentinel on Track 2 as received from the device.
Indicates Start Sentinel on Track 3 as received from the device.
trivpinchk R/W Set to
1
for trivial PIN checki.e., don’t allow 1234. (IntelliPIN)
trk_enable
R/W Enable reading and writing of individual tracks. The value of this
property is a string of three characters, with
0
representing
disabled tracks and
1
representing enabled tracks, e.g.,
110
enables
tracks 1 and 2 and disables track 3.
trk1data R Data from track 1 excluding start sentinel and end sentinel.
trk2data R Data from track 2 excluding start sentinel and end sentinel.
trk3data R Data from track 3 excluding start sentinel and end sentinel.
visa_mac1
visa_mac2
visa_mac3 R Message authentication codes returned by device after PIN is
collected (DUKPT mode only). (IntelliPIN)
wr_coer R/W Encode Coercivity Mode (MT-95). Specifies the energy level used
to encode the magnetic stripe:
0
= automatic selection
1
= LoCo only mode
2
= HiCo only mode
wr_secure R/W
0
indicates the card can be removed between a read and write
operation. Set this to
1
to turn on secure online encode mode (MT-
95).
xact_type R/W Transaction type –
d
= debit,
c
= credit (IntelliPIN).
