EAW DCS2 - Manual

• Advanced EAW horn technology provides prodigious output
in a relatively small enclosure
• Enhanced performance when used in multiples
• Dual heavy-duty 12-in woofers
The DCS2 bent horn subwoofer is engineered for use in per-
manent installations. The system loads purpose-designed dual
12-in drivers on an advanced bent bass horn, matching path
length to cone area. This technique maximizes driver effi-
ciency and provides greater output than traditional direct-
radiating dual 18-in subwoofers.
The DCS may be used for both high energy dance clubs and
live performance clubs. Multiple units can be configured in a
variety of ways to maximize effective horn size and low fre-
quency coupling. Horn-loading produces the very high levels
of sub bass reinforcement required in modern clubs.
The DCS2 enclosure features exceptionally rugged construc-
tion. Like all EAW products, it can be special ordered in virtu-
ally any color to match a specific décor. Six year warranty.
SPECIFICATIONS DCS2
FEATURES
PERFORMANCE
PHYSICAL
DESCRIPTION
APPLICATION
One Main Street, Whitinsville, MA 01588 508 234 6158 Toll Free 800 992 5013 FAX 508 234 8251 [email protected] www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. DCS2/2 pp October 2001 Printed in USA
Frequency Response
±3 dB 45 Hz to 250 Hz
-10 dB 35 Hz
Axial Sensitivity (dB SPL, 1 watt @ 1 m)
Sub Bass 107
Nominal Input Impedance (ohms)
Sub Bass 4
Power Handling (watts, continuous)
Sub Bass 1000
Calculated Output Limit (dB SPL @ 1 m)
Sub Bass Peak 143
Sub Bass Long Term 137
Product Group Avalon
Configuration Dedicated subwoofer
Sub Bass Subsystem 2x 12-in woofers, horn-loaded
Enclosure Material Exterior-grade Baltic birch plywood
Finish Wear-resistant textured black paint
Connectors 2x Neutrik NL4 Speakon
Grille Zinc coated perforated steel
Dimensions inches millimeters
Height 36.0 914
Width 36.0 914
Depth 36.0 914
Weights pounds kilograms
Net Weight 246 111.4
Shipping Weight 266 120.4
