EAW KF650z 2D - Manual

16.75
8.00
2X 8.75
28.98
33.25
22.42
28.98
PRODUCTION
2.13
KF650z
GRILLE PARTIALLY SHOWN
FRONT VIEW A-A
DIMENSIONS APPLY
TO BOTH SIDES
14.58
EASTERN ACOUSTIC WORKS
BACK 2.13
10.08
4.50
NOTES:
1. SYMBOL INDICATES 3.00 X 1.35 FLYTRACK.
2. SYMBOL INDICATES MOUNTING POINT,
3/8-16 THREADED HOLE (FLYTRACK).
3. SYMBOL INDICATES CENTER OF BALANCE.
4. WEIGHT APPROX. 130 LBS.
5. SHIPPING WEIGHT APPROX. 141 LBS.
4X HANDLE
12.25
20.62
10.00
20°
19.75
DIMENSIONS APPLY
TO TOP & BOTTOM
5.94
14.25
TOP
8.25 2X 6.44
6.05
A
(12.81)
C
L
A
ACCESS PANEL
C
L
INPUT
