- 8 -
2.6.2 Speed range:
1st 2.0 mph (3.22 km/h) 4th 4.1 mph (6.60 km/h)
2nd 2.7 mph (4.35 km/h) 5th 6.2 mph (9.98 km/h)
3rd 3.5 mph (5.63 km/h) Rev 3.1 mph (4.99 km/h)
2.7 WHEEL DRIVE SYSTEM
Banded double A-Section V-belts, single top-side idlers and replaceable bolt-on drive
sheaves and brake drums. (Single B-Section V-belts for the 32" Model)
2.8 TIRES
Drive Tires Size Qty. Tread Ply 4 Pressure Bearings
36” & 48” Models 13 x 6.5 – 6 2 Turf Master 4 14 psi (97kPa) Replaceable Ball
32” Model 13 x 5.0 – 6 2 Turf Saver 4 14 psi (97kPa) Replaceable Ball
Front Caster Tires
All Models 9 x 3.5 – 4 2 Smooth 4 22 psi (152kPa) Replaceable Roller
2.9 DECK
2.9.1 Cutting Width:
Model 32....................31.75 in. (80.7 cm)
Model 36....................35.38 in. (89.9 cm)
Model 48....................47.25 in. (120.0 cm)
2.9.2 Discharge: Right Side
2.9.3 Blade Size:
Model 32....................16.25 (41.3 cm) - Qty. 2
Model 36....................18.00 (45.7 cm) - Qty. 2
Model 48....................16.25 (41.3 cm) - Qty. 3
2.9.4 Type of Drive: Manual engagement of belt with over-center lock. Blade belt tension
is adjustable via turnbuckle. The 48 in. units have an additional belt which is also
adjustable.
2.9.5 Blade Brake: When the blade engagement control is moved to the disengaged
position a friction brake pad stops the rotation of the blades.
2.9.6 Deck Mounting: Bolted directly to engine deck
2.9.7 Cutting Height: Adjusts in 1/4" (.63 cm) or smaller increments by various
adjustments of caster spacers, blade spacers and axle height, from 1” to 4 1/4”
(2.5 cm - 10.8 cm).
2.10 DIMENSIONS
32" 36" 48”
Overall Width
Discharge chute down
42.5 in (107.8 cm) 46.1 in (117.1 cm) 58.2 in (148.0 cm)
Discharge chute up
(transport only)
32.8 in (83.2 cm) 36.4 in (92.5 cm) 48.1 in (122.2 cm)
Overall Length 78 in (198.1 cm) 78 in (198.1 cm) 73.0 in (185.4 cm)
Overall Height 40.0 in (101.6 cm) 40.0 in (101.6 cm) 40.0 in (101.6 cm)
Tread Width ∗ 32.05 in (81.4 cm) 35.6 in (90.4 cm) 35.6 in (90.4 cm)
Curb Weight ∗∗ 374 lbs (170 kg) 391 lbs (177 kg) 439 lbs (199 kg)
∗ To outside of tires.
∗∗ Weights will vary slightly depending on engine option.
