PUMP IDLER ASSEMBLY – 109-2182
-35-
Item Part No. Description Qty.
2 43-0940 Spacer-Hub, Blower ............................... 1
3 103-3504 Bearing, Spherical.................................. 2
4 103-3505 Seal, Double Lip .................................... 1
5 103-3506 Seal, Single Lip ...................................... 1
6 104-8301 Nut, Nyloc 3/8-16 Flg ............................. 1
7 106-7159 O-Ring ................................................... 2
Item Part No. Description Qty.
8 323-8 Screw, HH 3/8-16 x 1 1/2 ....................... 1
9 32120-10 Ring, Retaining ...................................... 2
10 302-19 Zerk, 1/4-28 Str...................................... 1
11 109-8076 Pulley, Idler 5" X 1" Nylon ...................... 1
12 109-7399 Pin, Spring Anchor ................................. 1
