ENGINE GROUP – 29HP KAWASAKI
-32-
Item Part No. Description Qty.
2 109-9905 Sheave, W/Hub...................................... 1
3 109-9282 Clutch, CMS-200 W/Spot Brake ............. 1
4 109-6919 Washer, Clutch ...................................... 1
5 1-603610 Washer, Spring Disc 7/16 ...................... 2
6V 109-9761 Screw, HH 7/16-20 x 1 1/2 W/Loctite ..... 1
7 3231-22 Bolt, Carriage 3/8-16 x 1 ........................ 1
10 33114-020 Screw, HH M8-1.25 x 20mm .................. 3
11 109-4490 Asm, Hose-Oil Drain W/Plug .................. 1
11:2 109-1012 Plug ....................................................... 1
12 98-5975 Washer, Spring Disc 3/8 ........................ 4
13 1-807259 Key, Machine 1/4 x 1/4 x 1 ..................... 1
14 109-8138-01 Anchor, Clutch ....................................... 1
15 323-7 Screw, HH 3/8-16 x 1 1/4 ....................... 4
Item Part No. Description Qty.
16 104-8301 Nut, Nyloc 3/8-16 Flg ............................. 1
24 1-303334 Washer, Spring Disc 5/16 ...................... 3
25 94-2413 U-Nut ..................................................... 2
26 3234-5 Screw, HH FLG 5/16-18 x 3/4 ................ 2
27 322-2 Screw, HH 5/16-18 x 5/8 ........................ 3
28 109-9280 Muffler, Small Engine ............................ 1
29 109-9250 Manifold, Exhaust .................................. 1
30 116-0203 Bracket, Muffler ..................................... 1
31 109-0296 Hose, Fuel Line 15" ............................... 1
32 2412-98 Clamp, Hose .......................................... 2
33 105-1853 Clamp, Hose .......................................... 1
34 3253-4 Washer, Lock 5/16 ................................ 3
Exmark red touch up paint (spray paint – P/N 1-850337 - .6 oz liquid bottle – P/N 103-9140)
V Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on clutch bolt.
