Design Spot 575B™
©Elation Professional, Los Angeles CA. 42 Design Spot 575B™
64-95 Strobe effect slow to fast
96-127 No function (shutter open)
128-159 Pulse-effect in sequences
160-191 No function (shutter open)
192-223 Random strobe effect slow to fast
224-255 No function (shutter open)
Dimmer intensity:
12 10 16
0-255 Intensity 0 to 100%
Fine Dimmer intensity:
17
0-255 Dimmer intensity fine
Iris:
0-191 Max. diameter to Min.diameter
192-223 Pulse opening fast to slow
13 11 18
224-255 Pulse closing slow to fast
Speed Pan/Tilt movement:
0-225 max to min speed
226-235 Blackout by movement
236-245 Blackout by all wheel changing
14 12 19
246-255 No function
Lamp on/off, reset, internal programs:
0-19 Color & gobo change normal
20-29 Color change to any position
30-39 Color & gobo change to any position
40-59 Lamp on
60-79 Lamp switch off
80-84 All motor reset
85-87 Scan motor reset
88-90 Colors motor reset
91-93 Gobo motor reset
94-96 Shutter & Dimmer motor reset
97-99 Other motor reset
100-119 Internal program 1 (secne1~8 of EEPROM)
120-139 Internal program 2 (secne9~16 of EEPROM)
140-159 Internal program 3 (secne17~24 of EEPROM)
160-179 Internal program 4 (secne25~32 of EEPROM)
180-199 Internal program 5 (secne33~40 of EEPROM)
200-219 Internal program 6 (secne41~48 of EEPROM)
220-239 Internal program 7 (secne49~56 of EEPROM)
15 13 20
240-255 Music Control (scene of Program 1)
