Design Spot 575B™
©Elation Professional, Los Angeles CA. 39 Design Spot 575B™
13. DMX CHANNEL TRAITS:
The chart below details the channel layout for 15 DMX channels (default).
In 8bit mode the “Pan Fine” and “Tilt Fine” channels are not used, thus converting the fixture
into a 13-channel DMX fixture.
CHANNEL 1: Pan Movement (max. 630° or 540˚ User Selectable)
CHANNEL 2: 16bit Pan Movement (pan fine)
CHANNEL 3: Tilt Movement (max. 265°)
CHANNEL 4: 16bit Tilt Movement (tilt fine)
CHANNEL 5: Color Wheel
CHANNEL 6: Gobo Wheel 1 (Rotating)
CHANNEL 7: Gobo Index, Gobo Rotation Speed/Direction (Gobo Wheel 1)
CHANNEL 8: Gobo Wheel 2 (Fixed)
CHANNEL 9: 3-Facet Prism Control
CHANNEL 10: Focus Control Motor (Near ~ Far)
CHANNEL 11: Strobe (0-13Hz), and Shutter close/open function + random strobe
CHANNEL 12: Dimmer (Intensity) Control
CHANNEL 13: Iris (Closed to Open)
CHANNEL 14: Speed Control (Pan/Tilt movement, blackout selection)
CHANNEL 15: Special (Auto program control + lamp on, motor reset, lamp switch off)
DMX channel function and values:
DMX channel functions and values (24 DMX channels):
Mode/Channel Value Function
St Ba Ex
PAN Movement 8bit :
1 1 1
0-255 Pan Movement
Pan Fine 16bit
2 2
0-255 Fine control of Pan movement
TILT Movement 8bit :
3 2 3
0-255 Tilt Movement
Tilt Fine 16bit
4 4
0-255 Fine control of Tilt movement
