o Example layout for Auro-3D 9.1 channel
system
This speaker configuration is optimized for Auro-3D playback.
FL FR
SW SL SR C
FHL FHR
SHL SHR
0
Set “Floor” to “5ch” and “Height Sp” to “4ch” in the menu when connecting in this
configuration. ( v p. 211)
Next, set “Height” - “Front Layout” to “Front Height” and “Rear Layout” to “Surround
Height”. ( v p. 215)
FR FL C SR SL SW FHR FHL SHR SHL z z
z For the best Auro-3D experience Surround Height speakers are recommended,
however you may substitute Rear Height speakers from a Dolby Atmos speaker
setup in place of Surround Height speakers.
