- 12 -
46. [IRIS OPEN]
47. [IRIS CLOSE]
48. [IRIS NORMAL]
49. [FOCUS NEAR]
51. [ZOOM TELE]
53. [INPUT]
54. [LAMP]
55. [MOVE]
56. [PRESET]
50. [FOCUS FAR]
52. [ZOOM WIDE]
57. [AF]
IRIS OPEN
IRIS CLOSE MOVE
IRIS NORMAL PRESET
FOCUS NEAR
INPUT
FOCUS FAR
LAMP
TELE WIDE
AF
ZOOM
Button Name Function
Reference
Page
46. P.28 IRIS OPEN To open the AUTO iris.
47. P.28 IRIS CLOSE To close the AUTO iris.
48. P.28 IRIS NORMAL To reset the AUTO iris to the initial value.
49. P.29, P.30 FOCUS NEAR To move the focus near.
50. P.29, P.30 FOCUS FAR To move the focus far.
51. P.19, P.22,
P.29
ZOOM TELE To zoom in.
52. P.19, P.22 ZOOM WIDE To zoom out.
53. P.22 INPUT To change the input system.
54. P.20, P.21 LAMP To turn ON/OFF the lamp.
55. P.30 MOVE To call the operating status of the Presenter
saved in [PRESET].
56. P.30 PRESET To save the operating status of the Presenter.
57. P.19, P.29 AF To focus automaticaly.
Wireless Remote Control
