11
DOOR REMOVAL / REVERSAL INSTRUCTIONS
To remove refrigerator handle:
(Handles may be easier to reverse while doors
are off.)
Figure 1 Style Handles
1. Remove two screws attaching handle to
top of refrigerator door.
2. Remove screw attaching bottom of handle
to door.
3. Remove two hole plugs and hinge pin
plug on top of door and install on opposite
side. Use Phillips head screwdriver to
remove plastic screw plug from front of
door and install on opposite side
Figure 2 Style Handles
1. Remove two screws attaching handle to
top of refrigerator door.
2. Swing top of handle away from door and
slide handle down and off of dovetail
button.
3. Remove screw and dovetail button and
install on other side, moving hole plugs
from corresponding holes to opposite side.
To attach refrigerator handle:
Figure 1 Style Handles
1. Secure bottom of handle with screws.
2. Secure top of handle with screws.
Figure 2 Style Handles
1. Start with handle offset away from door.
Place bottom of handle over dovetail
button, swing handle into an upright
position and pull upward, locking it into
place.
2. Secure top of handle with screws.
To Attach Trim:
1. Slide both trim locks out of trim.
2. Insert new adhesive trim locks contained
in your literature pack.
3. Install trim to handle by sliding under base
of handle. Carefully align trim and press
down at trim lock locations.
4. Use rubbing alcohol to remove any
adhesive residue from old trim lock
locations.
Screw
Handle
Full
Length
Trim
Screw
Trim
Lock
Adhesive
Trim Lock
Figure 1
Screw
Handle
Full
Length
Trim
Trim
Lock
Lock Handle
over
Dovetail
Button
Dovetail
Button
Screw
Adhesive
Trim Lock
Figure 2
