LED Indicators
POWER LED (Green)
• Lights when the power supply is on.
• Goes out when the power supply is turned off.
ERROR LED (Orange)
Lights or flashes when the scanner is offline.
• Lights after the power is turned on or after a reset (offline). Automatically goes out when the
scanner is ready.
• Flashes when an error occurs or when waiting for document removal. (For details about the
flash codes, see
.)
• Out during regular operation (online).
When waiting for document removal, the ERROR LED flashes as shown below.
POWER LED
ERROR LED
DOCUMENT LED
Approx.160 ms
Approx.160 ms
