19
7.3 COMPONENTS FOR 109-3884 ASSEMBLY
Item
Part No.
Description
Qty.
1 109-3608-01 Bracket, Pedal Pivot ............................. 1
2 109-3609-01 Pedal, Gate .......................................... 1
3 109-3610 Rod, Pedal Link ................................... 1
4 109-3877-01 Channel, Pedal Link ............................. 1
Item
Part No.
Description
Qty.
5 109-3878 Rod, Pedal Pivot .................................. 2
6 109-3879-01 Latch, Gate Pedal ................................ 1
7 3256-23 Washer, 5/16 SAE ............................... 1
8 32112-11 Pushnut, Washer Cap.......................... 6
