Page 16 of 125 Swarm Wash FX ILS User Manual Rev. 5
Operation
– 15 SMD strobes program
000  009 No function
010  019 SMD strobes program 1, slow to fast
020  029 SMD strobes program 2, slow to fast
030  039 SMD strobes program 3, slow to fast
040  049 SMD strobes program 4, slow to fast
050  059 SMD strobes program 5, slow to fast
060  069 SMD strobes program 6, slow to fast
070  079 SMD strobes program 7, slow to fast
080  089 SMD strobes program 8, slow to fast
090  099 SMD strobes program 9, slow to fast
100  109 SMD strobes program 10, slow to fast
110  119 SMD strobes program 11, slow to fast
120  200 Full on
201  255 Sound-active SMD strobe
– 16
Laser color
(Ch. 17 must be active for
strobe)
000  009 No function
010  049 Red
050  089 Green
090  129 Red and green alternating strobe
130  169 Red and strobing green
170  209 Green and strobing red
210  255 Red and green
– 17 Laser strobe
000  004 No function
005  254 Laser strobe, fast to slow
255 Sound-active laser strobe
– 18 Laser rotation
000  004 Stop
005  127 Counterclockwise rotation, slow to fast
128  133 Stop
134  255 Clockwise rotation, slow to fast
For manual operation of LEDs and lasers using DMX control, set Channel 1 to 000  015.
2-Ch 18Ch Function Value Percent/Setting
