1-5
1.2. Specifications
Pickup Device 1/4'' SONY Type EXview HAD CCD
Video Format NTSC or PAL
Scanning System NTSC: 525 TV lines, 60 fields/sec
PAL: 625 TV lines, 50 fields/sec
Picture Elements 768 x 494 ( NTSC ) , 752 x 582 ( PAL )
Horizontal Resolution 480 TVL
Sensitivity 0.7 Lux/F=1.4
S/N Ratio (AGC OFF) Over 50dB
Electronic Shutter 1~1/10,000 (s)
Digital Slow Shutter Yes
Shutter Selection Yes
Lens Type 18x optical zoom , f=4.1 mm (wide) to 73.8mm (tele) , F1.4 to
F3.0
Zoom Ratio 216x max (18x Optical and 12x Digital Zoom )
Day/Night Yes
Black Light Comp. ON/OFF
Auto Gain Control Auto
White Balance Auto/Indoor/Outdoor
Video Output BNC 1.0Vp-p , 75ohm
Sync. Mode Line Lock/Internal Sync
Power Source 24VAC
Power Consumption 18W; 70W with heater
Operating Temperature -40°C~50°C ; -40°F~122°F
Focus Control One push/Auto/Manual
Horizontal Rotation
Speed
0.1°/s~360°/s (1-239 grade shift gears)
Horizontal Rotation
Range
360° unlimited rotation
Tilt Rotation Range 90° pendulum motion
Auto Flip Rotates 180° when camera tilts to the vertical position
Auto Zoom Speed
Control
Control speed auto-adjusted according to zoom length changing
Auto Pan, 2 Points
Scanning
Can set freely
Auto Pan Speed 1~239 grades available
Dwell Time (2 points) 1~239 second available
