Connections with audio connectors, E-23 – Epson WorkForce V-1100 User Manual
Page 23
E-23
Connecting Personal Computers and Video Equipment
Connections with Audio Connectors
* Make the connection to the projector's AUDIO jack using an audio cable.
* The built-in speaker of the projector provides monaural audio.
* To enjoy convincing audio reproduction, please connect the audio output of the video equipment to
your audio system.
PC
VIDEO
AUDIO
R
L
AUDIO
Audio cable (Supplied item)
Video equipment, personal computer
Note
The AUDIO jack of the projector is a 2.5 mm diameter stereo mini jack. Connection is not possible using the
common (3.5 mm diameter) stereo mini jack cable from the headphone jack of the personal computer or video
equipment.
White
Red
