Placement Guide
●
Use this information as a guide to find out about the screen size when the projector is placed at a
certain location, or to find out the approximate size of a screen that will be required.
●
The projection distance over which focussing is adjustable is 1.2 m (3.9 feet) to 6.6 m (21.7 feet). The
projector should be placed within this range.
Screen Size and Projection Distance
Height from center
of lens to bottom
edge of the projec-
tion
Height from center of
lens to top edge of the
projection
Unit: m (feet)
Lens surface of
the main unit
Screen Size Designation (Inches)
