Please refer to below illustration for M6 eye bolt length.
Note
• Your LCD Display is shipped with screws attached to the
rear of the LCD Display depending on the LCD Display
model. (They are fastened in the screw holes for wall
mounting.) Be sure to remove the upper two screws prior
to anchoring the LCD Display to a wall.
• Securing the LCD Display to the Stand without securing
the LCD Display and the Stand to the wall provides
minimum protection against the LCD Display toppling
over. For further protection, be sure to follow the three
measures recommended.
Wall-mount holes
Rope or
chain (not
supplied)
M6 eye bolts (not supplied)
Wall-anchor
(not supplied)
10 mm – 12 mm
LCD Display’s rear cover
M6 eye bolt
