D:\_SONY TV\SY21_B2B_UCF_RG_131\01US\5027091131_US.fm master page: Right
FW-100BZ40J / 75BZ30J / 65BZ30J / 55BZ30J1 / 55BZ30J / 50BZ35J / 50BZ30J / 43BZ35J / 43BZ30J / 32BZ30J
5-027-091- 13 (1)
15 US
US
(b) Responses from the LCD Display to the controller
Examples of RS-232C communication command are explained below.
For more details on RS-232C, please contact your sales representative.
You can control the LCD Display via IP from an HTML5/Android application on the LCD Display
or on the external device. You can manage and monitor information of input/power, start and
terminate applications, control the display such as input source and volume. You can also
restrict commands by the authentication function.
No. Item Value
1 Header 0x70 Answer
2 Answer 0x00 Completed (Normal End)
0x01 : Limit Over
(Abnormal End-Exceed maximum value)
0x02 : Limit Over
(Abnormal End-Exceed minimum value)
0x03 : Command Canceled (Abnormal end)
0x04 : Parse Error (Data Format Error)
3 Check Sum 0xXX
Command example
Control Head Category Function Length Data 1 Data X Checksum
Power
on/off
0x8C 0x00 0x00 0x02
0x00 (off) - 0x8E
0x01 (on) - 0x8F
HDMI
input
selection
0x8C 0x00 0x02 0x03
0x04
(HDMI)
0x01 (#1) 0x96
0x02 (#2) 0x97
0x03 (#3) 0x98
0x04 (#4) 0x99
IP
Supported IP protocol
Protocol name Layer Format Authentication Explanation
REST API HTTP JSON-RPC Yes The APIs whose purpose is device
control.
IRCC-IP HTTP SOAP Yes Infrared Compatible Control over
Internet Protocol.
The technology and formats to
transmit remote control
commands via the Internet.
Simple IP
control TCP Byte stream N/A Only typical functions are
supported.
