AN-X-DCSNet2 Page 23
2. Map DCS data to the scheduled data and save the mappings as a
comma separated variable (CSV) file
3. Send the configuration file to AN-X
Requirements
• RSLogix 5000 version 12 or above
• ControlLogix processor with firmware version 12 or above
• 100 Mbit Ethernet network and ENBT modules. We strongly
recommend using Ethernet switches rather than hubs
Reference
Allen-Bradley publication EtherNet/IP Media Planning and Installation
Manual
, publication ENET-IN001A-EN-P
Configuring AN-X in RSLogix 5000
The AN-X-DCSnet2 emulates a 17-slot 1756 chassis with an ENBT/A in
slot 16 and generic modules in slots 0 to 15.
Exclusive Owner Connection
To configure the AN-X-DCSnet2 in RSLogix 5000:
1. Right click on the ControlLogix Ethernet bridge module that will be
communicating with the AN-X and select Add Module. Add a
1756-ENBT/A module. Set the Major Rev to 1.
