A standard removable power distribution box provides flexibility when installing
the UPS. Optional power distribution boxes are available with a built-in
maintenance bypass switch that allows hot-swapping of the entire UPS.
PD-HDWR-MBS
Includes bypass
Input: hardwire
Output: hardwire
PD-006
Includes bypass
Input: L14-30
Output: (4) L5-20
(2) L6-30 PD-005
Includes bypass
Input: L14-30
Output: (4) L5-20
(2) L5-30
PD-HDWR
Input: hardwire
Output: hardwire
PD-002
Includes bypass
Input: L14-30
Output: (2) 5-15/20
(2) L6-20 PD-003
Includes bypass
Input: L14-30
Output: (4) 5-15/20
(2) L6-30
6 kVA Power Output Distribution Options
