sPeCifiCAtions

viDeo

Gain.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Unity (0 dB), or (1.1 dB) 110%, switch-selectable

(When input = 0.7 V, output = 0.7 V or 0.8 V, respectively.)

Peaking.. . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 dB or +6 dB at 100 MHz, switch-selectable

Bandwidth.. . . . . . . . . . . . . . . . . . . . . . . . . 350 MHz (-3 dB), fully loaded

Differential phase error.. . . . . . . . . <1.0º at 5 MHz

Differential gain error.. . . . . . . . . . . <1.0% at 5 MHz

viDeo inPut

Number / Signal type.. . . . . . . . . . . . 1 RGBHV, RGBS, RGsB, RsGsBs, component video, S-video, composite video

Connectors.. . . . . . . . . . . . . . . . . . . . . . . . 5 female BNC

Nominal level (at unity gain).. . . . . 1 Vp-p for Y of component video and S-video, and for composite video

0.7 Vp-p for RGB
0.3 Vp-p for R-Y and B-Y of component video, and for C of S-video

Minimum / Maximum levels... . . Analog: 0.3 V to 1.5 Vp-p with no offset at unity gain

Impedance... . . . . . . . . . . . . . . . . . . . . . . . 75 ohms

Horizontal frequency. . . . . . . . . . . . . 15 kHz to 180 kHz

Vertical frequency.. . . . . . . . . . . . . . . . 15 Hz to 170 Hz

Return loss.. . . . . . . . . . . . . . . . . . . . . . . . <-38 dB @ 5 MHz

DC offset (max. allowable)... . . . . . . 5.0 V (in AC coupling mode)

Input coupling... . . . . . . . . . . . . . . . . . . . AC/DC, switch-selectable

viDeo outPut

Number / Signal type.. . . . . . . . . . . . 2, 4, or 6 RGBHV, RGBS, RGsB, RsGsBs, component video, S-video,

composite video (follows input type)

Connectors.. . . . . . . . . . . . . . . . . . . . . . . . (2, 4, or 6) x 5 BNC female

Nominal level.. . . . . . . . . . . . . . . . . . . . . 1 Vp-p for Y of component video and S-video, and for composite video

0.7 Vp-p for RGB
0.3 Vp-p for R-Y and B-Y of component video, and for C of S-video

Minimum / Maximum levels... . . 0.3 Vp-p to 1.5 Vp-p (follows input)

Impedance... . . . . . . . . . . . . . . . . . . . . . . . 75 ohms

Return loss.. . . . . . . . . . . . . . . . . . . . . . . . <-44 dB @ 5 MHz

DC offset.. . . . . . . . . . . . . . . . . . . . . . . . . . . ±5 mV with input at 0 offset

synC

Input / Output type.. . . . . . . . . . . . . . . RGBHV, RGBS, RGsB, RsGsBs

Input level.. . . . . . . . . . . . . . . . . . . . . . . . . Analog or TTL: 0.5 V to 5 Vp-p

Output level.. . . . . . . . . . . . . . . . . . . . . . . TTL: 5 Vp-p, unterminated

Input impedance.. . . . . . . . . . . . . . . . . 510 ohms

Output impedance.. . . . . . . . . . . . . . . 75 ohms

Max. input voltage.. . . . . . . . . . . . . . . 5.0 Vp-p

Max. propagation delay.. . . . . . . . . 35 ns

Max. Rise / Fall time.. . . . . . . . . . . . . 4 ns

Polarity.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . Positive or negative (follows input)

ControL / remote — Distribution AmPLifier

Contact closure.. . . . . . . . . . . . . . . . . . . (1) 9-pin female D connector

Contact closure

pin configurations.. . . . . . . . . . . . . . . . Pin 1 = mute output #1, pin 2 = mute all outputs, pin 3 = reserved,

pin 4 = mute output #2, pin 5 = GND, pin 6 = mute output #3,
pin 7 = mute output #4, pin 8 = mute output #5, pin 9 = mute output #6

GenerAL

Power... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 VAC to 240 VAC, 50/60 Hz, 10 watts, internal, universal

Temperature / Humidity.. . . . . . . . . Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Rack mount
DA2 RGBHV

.. . . . . . . . . . . . . . . . . . . . . . . . Yes, with optional 1U rack shelf, part #60-190-01

DA4 RGBHV and DA6 RGBHV

. . . . . Yes, with included brackets

Enclosure type.. . . . . . . . . . . . . . . . . . . . Metal

Enclosure dimensions
DA2 RGBHV

.. . . . . . . . . . . . . . . . . . . . . . . . 1.7" H x 8.7" W x 9.4" D (1U high, half rack wide)

4.3 cm H x 22.1 cm W x 23.9 cm D

DA4 RGBHV and DA6 RGBHV

. . . . . 1.75" H x 17.5" W x 8.5" D (1U high, full rack wide)

4.4 cm H x 44.4 cm W x 21.6 cm D
(Depth excludes connectors.)

Product weight
DA2 RGBHV

.. . . . . . . . . . . . . . . . . . . . . . . . 2.0 lbs (0.9 kg)

DA4 RGBHV

.. . . . . . . . . . . . . . . . . . . . . . . . 3.7 lbs (1.7 kg)

DA6 RGBHV

.. . . . . . . . . . . . . . . . . . . . . . . . 3.9 lbs (1.8 kg)

Shipping weight
DA2 RGBHV

.. . . . . . . . . . . . . . . . . . . . . . . . 4 lbs (2 kg)

DA4 RGBHV and DA6 RGBHV

. . . . . 7 lbs (4 kg)

Vibration.. . . . . . . . . . . . . . . . . . . . . . . . . . . ISTA 1A in carton (International Safe Transit Association)

Listings.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . UL, CUL

Compliances.. . . . . . . . . . . . . . . . . . . . . . CE, FCC Class A, VCCI, AS/NZS, ICES

MTBF.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30,000 hours

Warranty.. . . . . . . . . . . . . . . . . . . . . . . . . . . 3 years parts and labor

NOTE: All nominal levels are at ±10%. Specifications are subject to change without notice.

DA RGBHV Series

c o m p u t e r & r G b D i s t r i b u t i o n A m p l i f i e r s
