DA RGBHV Series
c o m p u t e r & r G b D i s t r i b u t i o n A m p l i f i e r s
DA2 RGBHV
Two Output Wideband RGBHV Distribution Amplifier
unique feAtures
• Input: One set of female BNC connectors
• Outputs: Two sets of female BNC connectors
• 1U, half rack width metal enclosure
moDeL
version DesCriPtion PArt #
DA2 RGBHV 1x2 RGBHV .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-488-01
DA4 RGBHV
Four Output Wideband RGBHV Distribution Amplifier
unique feAtures
• Input: One set of female BNC connectors
• Outputs: Four sets of female BNC connectors
• 1U, full rack width metal enclosure
• Includes rack ears, part # 70-077-03
moDeL version DesCriPtion PArt #
DA4 RGBHV 1x4 RGBHV .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-489-01
moDeL
version DesCriPtion PArt #
DA6 RGBHV 1x6 RGBHV .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-490-01
DA6 RGBHV
Six Output Wideband RGBHV Distribution Amplifier
unique feAtures
• Input: One set of female BNC connectors
• Outputs: Six sets of female BNC connectors
• Includes rack ears, part # 70-077-03
oPtionAL ACCessories moDeL DesCriPtion PAGe PArt #
For DA2 RGBHV only
RSU 129 1U 9.5" Deep Universal Rack Shelf Kit .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 819 60-190-01
MBU 129 1U, 1/2 Rack Width Under-Desk Mount Kit for Four-Piece Enclosure .. . . . . . . . . . . . page 816 70-219-01
DA RGBHV Series Accessories
inCLuDeD ACCessories moDeL DesCriPtion PAGe PArt #
For DA4 RGBHV & DA6 RGBHV
MBD 149 1U, Full Rack Width, Rack Mount and Through-Desk Kit for Four-Piece Enclosure .. . page 817 70-077-03
544
