Rosen Aviation Remote Display System
Document Number: 105478 Revision: F
Date: 06/23/14
Template: 4.4.1.6FM2; Revision A; 12/06/12 Page 22 of 38
10. TECHNICIAN MENU
To protect the display from accidental or unintentional adjustments, the Technician Menu is
accessible only with a special button combination. To avoid repeating this button sequence after
each change, the menu remains active until you manually close it.
Whenever there is a change to the Technician Menu, exit the
OSD, and cycle power for the changes to be fully accepted.
To open the Technician Menu, start with the display on, and press the following buttons in this
order:
1. Press INFO.
2. With the Back option highlighted on the Main Menu, press the ▲▼▲▼▲▲▲ buttons
and then press MENU.
3. The Technician Menu opens. The options you see depend on the Mode Menu
settings. Splash Screen and Source Mode menu will appear only when the Mode
MenuOperation Mode is set to Standard.
Figure 23 Technician Main Menus
To navigate the menu options, press the ▲ or ▼ buttons.
To close the Technician menu and return to the Info Page, select the Back option and press
MENU
. To close the Technician menu and the OSD, press EXIT.
Note:
The Main Menu options are not selectable while the Technician Menu is open.
Press Back
to exit the
Technician
Menu and
return to the
Info page
RMEB 0700-104 RMEB 0700-107
Available
only with
Standard
Operation
Mode active
