Quick Guide for DG4000 9
14. Waveforms
Sine----Sine
Generate a Sine waveform with frequency from 1μHz to 160MHz.
 When the function is enabled, the backlight of the button turns on.
 Enable to change Frequency/Period, Amplitude/High Level, Offset/Low Level
and Start Phase of the Sine waveform.
Square----Square
Generate a Square waveform with frequency from 1μHz to 50MHz and variable
duty cycle.
 When the function is enabled, the backlight of the button turns on.
 Enable to change Frequency/Period, Amplitude/High Level, Offset/Low Level,
Duty Cycle and Start Phase of the Square waveform.
Ramp----Ramp
Generate a Ramp waveform with frequency from 1μHz to 4MHz and variable
symmetry.
 When the function is enabled, the backlight of the button turns on.
 Enable to change Frequency/Period, Amplitude/High Level, Offset/Low Level,
Symmetry and Start Phase of the Ramp waveform.
Pulse----Pulse
Generate a Pulse waveform with frequency from 1μHz to 40MHz and variable
pulse width and edge time.
 When the function is enabled, the backlight of the button turns on.
 Enable to change Frequency/Period, Amplitude/High Level, Offset/Low Level,
Pulse Width/Duty Cycle, Leading Edge Time, Trailing Edge Time and Delay
of the Pulse waveform.
Noise----Noise
Generate a Gauss Noise with 120MHz bandwidth.
 When the function is enabled, the backlight of the button turns on.
 Enable to change Amplitude/High Level and Offset/Low Level of the Noise.
Arb----Arbitrary Waveforms
Generate an arbitrary waveform with frequency from 1μHz to 40MHz.
 Provide Step-by-Step output mode.
