MTP U R Series • Introduction
About this Manual
This manual details the installation and operation of the Extron
MTP U R series of mini twisted pair universal receivers.
• MTP U R RSA SEQ mini twisted pair receiver with
RS-232, audio, and skew equalization
• MTP U R RS SEQ mini twisted pair receiver with RS-232
and skew equalization
• MTP U R RS mini twisted pair receiver with RS-232
• MTP U R A mini twisted pair receiver with audio
In this manual the following terms are applicable:
• “transmitter” refers specifically to the MTP transmitter.
• “MTP U R” or “receiver” refers to any MTP U R model.
• “SEQ receiver” refers specifically to the MTP U R RS SEQ
and MTP U R RSA SEQ receivers with skew equalization.
About the MTP Universal Receivers
Extron MTP U R RSA SEQ, MTP U R RS SEQ, MTP U R RS, and
MTP U R A receivers are for long distance distribution of RGB,
component (bi/tri level), S-video, or composite video signals
over twisted pair cables. The receivers auto detect video formats
and RS-232/audio signals, enabling the signal to be output on
the appropriate rear panel connector (see table below). RS-232
serial communication, dual mono audio, and skew equalization,
are available on some devices.
Feature Connectivity MTP U R
RSA SEQ
MTP U R
RS SEQ
MTP U R RS MTP U R A
RGBHV,
RGBS output
15-pin HD (1) ✔ ✔ ✔ ✔
Y, R-Y, B-Y
output
BNCs (3)
or 15-pin HD(1)
BNCs 15-pin HD 15-pin HD 15-pin HD
S-video
output
4-pin mini DIN
(1)
✔ ✔ ✔ ✔
Composite
video output
BNC (1) ✔ ✔ ✔ ✔
Dual Mono
audio output
5-pin captive
screw (1)
✔ ✘ ✘ ✔
RS-232
connectivity
5-pin captive
screw (1)
✔ ✔ ✔ ✘
Level
adjustment
✔ ✔ ✔ ✔
Peaking
adjustment
✔ ✔ ✔ ✔
Skew
adjustment
✔ ✔ ✘ ✘
Introduction
Figure 1 — MTP U R series features
2
