3.15. PHASE 10 - “GAUDI’ WITH COMPARTMENT"- ASSEMBLY OF COMPARTMENT
TOP (element 12)
LATO SERVIZIO FORMA PUROB95
LATO CARICAMENTO FORMA PUROB95
Fasten the
compartment top using 6 self-tapping screws 4.2X16.
