Page 20
DVI DL 201 Tx/Rx • Installation
Installation, cont’d
2-8
Panel Features
DVI DL 201 Tx front panel features
The illustration below shows the front panel features of the
DVI DL 201 Tx.
DVI DL 201 Tx
DVI DUAL LINK TRANSMITTER
1
DVI DL 201 Tx front panel features
a
LED — An amber light indicates that the DVI DL 201 Tx is
receiving power from a power supply or remotely, through
the receiver. A green light indicates that the transmitter is also
receiving a video signal.
