Two Panel Sizes and Two Series
The one-piece type LUMA monitors are offered in two grades – the LMD-2010
and LMD-1410, which provide the basic features for professional picture
monitoring, and the LMD-2020 and LMD-1420 for more advanced monitoring.
Model Types
Input Versatility
As standard, all one-piece type LUMA monitors come equipped with a full
range of analog SD inputs including analog composite NTSC and PAL, Y/C
(S-Video), and 525i/625i component and RGB.
The LMD-2020 and LMD-1420 add the further capability of SD-SDI input
through the use of the optional BKM-320D SD-SDI input adaptor.
Signal Interfaces
One-piece Type
8
LMD-2020
LMD-1420
LMD-1410
LMD-2010
Connector Panel for LMD-2020/LMD-1420
Connector Panel for LMD-2010/LMD-1410
The one-piece type LUMA monitors offer the best quality-per-cost balance for SD signal monitoring.
They are designed exclusively for SD video input and offer the most natural picture reproduction of such
(525/60i and 625/50i) signals. With all signal processing and interfaces built into their slim panels, these
monitors offer a variety of analog interfaces ranging from analog composite and Y/C to component video.
In addition, SD-SDI input is offered on the higher-grade LMD-2020 and LMD-1420 models.
These LUMA monitors are optimized to replace CRT monitors at the Sony PVM-L2 and PVM-L1 range.
LINE A
LINE B
PARALLEL REMOTE
RGB/COMPONENT
VIDEO
IN
OUT
VIDEO
IN
OUT
G/Y
IN
OUT
B/P
B
IN
OUT
EXT
SYNC
IN
OUT
R/P
R
IN
OUT
AUDIO
IN
OUT
AUDIO
IN
OUT
AUDIO
IN
OUT
AC IN
OPTION
AUDIO IN
OPTION IN
AC In
LINE A [composite (BNC), Y/C
(4 pin mini-DIN), Audio (RCA pin)]
LINE B [composite (BNC), Audio (RCA pin)]
PARALLEL REMOTE (modular connector)
RGB/COMPONENT (BNC), Audio (RCA pin)
ENT SYNC In/Out (external sync) (BNC)
OPTION AUDIO In (RCA pin)
OPTION In connector for SD-SDI board (BKM-320D)
AC In
LINE A [composite (BNC), Y/C
(4 pin mini-DIN), Audio (RCA pin)]
LINE B [composite (BNC), Audio (RCA pin)]
PARALLEL REMOTE (modular connector)
RGB/COMPONENT (BNC), Audio (RCA pin)
OPTION
AUDIO
IN
OPTION
IN
EXT
SYNC
IN
OUT
LINE A
LINE B
PARALLEL REMOTE
RGB/COMPONENT
VIDEO
IN
OUT
VIDEO
IN
OUT
G/Y
IN
OUT
B/P
B
IN
OUT
R/P
R
IN
OUT
AUDIO
IN
OUT
AUDIO
IN
OUT
AUDIO
IN
OUT
AC IN
LMD-2020
4:3
20.1-inch
Supplied
Optional MB-527
100 x 100 mm
LMD-1420
4:3
14-inch
Supplied
Optional MB-526
100 x 100 mm
LMD-2010
4:3
20.1-inch
Supplied
Optional MB-527
100 x 100 mm
LMD-1410
4:3
14-inch
Supplied
Optional MB-526
100 x 100 mm
* Viewable area measured diagonally.
Panel
Aspect
Ratio
Panel Size
*
Desktop
Stand
Mounting Holes (mm)
19-inch Rack
VESA Mounting
LMD-2020
480/60i*
525
483
O
O
O
O
LMD-1420
575/50i
625
575
LMD-2010
480/60i*
525
483
O
O
O
—
LMD-1410
575/50i
625
575
* Also accepts 59.94 Hz field rate.
System
Total
Line
Active Line
Composite
S-Video
Component/
RGB
SD-SDI
The Optional
BKM-320D
Input Signal
Interface
