LMD-322W
LMD-232W
with the optional SU-558
monitor stand
LMD-212
with the optional SU-558
monitor stand
LMD-172W
with the optional SU-558
monitor stand
LMD-152
with the optional SU-558
monitor stand
Separate Type
(Studio Type)
Picture Performance
Type
a-Si TFT Active Matrix LCD with a multi-layer AR-coated protection panel
Resolution
1280 x 768 dots
1024 x 768 dots
1280 x 768 dots
1024 x 768 dots
Pixel efficiency
99.99%
Dot pitch
0.537 x 0.537 mm
0.3915 x 0.3915 mm
0.420 x 0.420 mm
0.284 x 0.284 mm
0.297 x 0.297 mm
Picture Size (H x W)
Approx. 687 x 412 mm
Approx. 501 x 301 mm
Approx. 430 x 323 mm
Approx. 364 x 218 mm
Approx. 304 x 228 mm
(Diagonal)
(27 1/8 x 16 1/5 inches)
(19 3/4 x 11 7/8 inches)
(17 x 12 3/4 inches)
(14 3/8 x 8 5/8 inches)
(12 x 9 inches)
802 mm (31 5/8 inches)
584 mm (23 inches)
538 mm (21 1/4 inches)
424 mm (16 3/4 inches)
380 mm (15 inches)
Aspect
15:9
4:3
15:9
4:3
Colors
16,770,000 colors
Viewing Angle
85°/85°/85°/85° (typical) (up/down/left/right contrast>10:1)
Input
Display Input connector
Digital input
DVI-D
Dot clock
25.175 MHz
68.250 MHz
25.175 MHz
68.250 MHz
25.175 MHz
65.000 MHz
25.175 MHz
68.250 MHz
25.175 MHz
65.000 MHz
Scanning Frequency
Horizontal
31.469 kHz
47.396 kHz
31.469 kHz
47.396 kHz
31.469 kHz
48.363 kHz
31.469 kHz
47.396 kHz
31.469 kHz
48.363 kHz
Vertical
59.940 Hz
59.995 Hz
59.940 Hz
59.995 Hz
59.940 Hz
60.004 Hz
59.941 Hz
59.995 Hz
59.941 Hz
60.004 Hz
General
Power Consumption
Approx. 120 W
Approx. 65 W
Approx. 84 W
Approx. 53 W
Approx. 29 W
Power requirement
AC 100 to 240 V ±10%, 50/60 Hz
DC 16.5 V
DC 16.5 V
DC 16.5 V/12V
DC 16.5 V/12 V
Operating Temperature
0 to 35 °C (32 to 95 °F)
Operating Humidity
30 to 80% (no condensation)
Storage & Transport Temperature
-10 to 40 °C (14 to 104 °F)
Storage & Transport Humidity
0 to 80%
Operating/Storage/Trans. Pressure
700 to 1060 hPa
Dimensions (W x H x D)
790 x 512 x 94 mm *
563 x 372 x 78 mm *
515 x 409 x 81 mm *
441 x 294 x 76 mm *
379 x 297x 70 mm *
(31
1
/
8
x 20
1
/
4
x 3
3
/
4
inches) *
(22
1
/
4
x 14
3
/
4
x 3
1
/
8
inches) *
(20
3
/
8
x 16
1
/
8
x 3
1
/
4
inches) *
(17
3
/
8
x 11
5
/
8
x 3 inches) *
(15 x 11
5
/
8
x 2
7
/
8
inches) *
Approx. 17.6 Kg
Approx. 6.4 Kg
Approx.6.7 Kg
Approx. 4.8 Kg
Approx. 4.0 Kg
Mass
(Approx. 38 lb 13 oz)**
(Approx. 14 lb 2 oz)**
(Approx. 15 lb 7 oz)**
(Approx. 10 lb 9 oz)**
(Approx. 8 lb 13oz)**
Approx. 49.6 Kg
Approx. 11.6 Kg
Approx. 11.9 Kg
Approx. 10.0 Kg
Approx. 9.2 Kg
(Approx. 108 lb 22 oz)***
(Approx. 25 lb 9 oz)***
(Approx. 26 lb 4 oz)***
(Approx. 21 lb 1 oz)***
(Approx. 20 lb 4oz)***
AC cord, AC plug holder,
Supplied Accessories
Display interface cable, Warranty card,
Display interface cable, Warranty card, Operating instructions
Operating instructions
* without the optional monitor stand and not including the projection parts ** without the optional SU-558 monitor stand, SU-559 for LMD-322W *** with the optional SU-558 monitor stand, SU-559 for LMD-322W
Dimensions
LMD-322W
LMD-232W
LMD-212
LMD-172W
LMD-152
Unit: mm (inches)
