Separate Type
5
Input Versatility
Multi-format Signal Support
The MEU-WX2 Multiformat Engine Unit of the separate type
LUMA monitors can accept almost any SD or HD video format,
both analog and digital. These include composite NTSC and PAL,
component 480/60i and 575/50i, progressive 480/60P and
576/50P, and high-definition 1080/60i, 1080/50i, and 720/60P. It
can also accept 1080/24PsF and 1080/25PsF.
Standard interfaces include analog composite (NTSC/PAL),
525i/625i component and RGB, and Y/C*
1
. Digital interfaces are
offered as optional boards to meet budgetary and user needs.
To keep the unit compact (1RU high), the analog inputs share the
same four BNC connectors, each with loop-through capability.
The MEU-WX2 also accepts various types of analog computer
signals. With its high-performance scan converter, it can display
PC signals from VGA to SXGA*
2
.
*1 Y/C signals must be input via the BNC connectors of the MEU-WX2 using an
S-Video-to-BNC conversion connector.
*2 SXGA images are down-converted for display.
Input Signals/Input Adaptors
Signal-interface Options
The MEU-WX2 can accept HD-SDI, SD-SDI, or DV signals via
the following optional input adaptors.
BKM-220D, SD-SDI 4:2:2 Input Adaptor*
1
• SD-SDI signal input (x2) • SD-SDI monitor output (x1)
• Power consumption: 1.5 W
BKM-243HS, HD-SDI/SD-SDI Input Adaptor*
1
• HD-SDI/SD-SDI signal input (x2) • HD-SDI/SD-SDI monitor output (x1)
• Power consumption: 2 W
•HD-SDI and SD-SDI signals are automatically detected.
BKM-255DV*, DV Input Adaptor*
1,
*
2
• DV signal port (x 2) • Power consumption: 4 W
*1 Embedded audio is supported.
*2 The full command set of the AV/C (Audio/Video and Control) protocol is
not supported.
Preset Computer Input Frequencies
The MEU-WX2 is factory preset to accept 19 typical computer
input signal frequencies.
Preset Input Frequencies
575/50i
625
575
16:9/4:3
O
O
O
O
O
480/60i
*
525
483
16:9/4:3
O
O
O
O
O
576/50P
625
576
16:9/4:3
—
O
—
—
—
480/60P
525
483
16:9/4:3
—
O
—
—
—
1080/24PsF
1125
1080
16:9
—
O
—
O
—
1080/50i
1125
1080
16:9
—
O
—
O
—
1035/60i
*
1125
1035
16:9
—
O
—
O
—
1080/60i
*
1125
1080
16:9
—
O
—
O
—
720/50P
750
720
16:9
—
O
—
O
—
720/60P
750
720
16:9
—
O
—
O
—
* Also accepts 59.94 Hz field rate.
System
Total
Line
Active
Line
Aspect
Ratio
Input Signal
Interface
Composite/
Y/C
RGB/
Component
SD-SDI
SD-SDI/
HD-SDI
DV
Standard
Optional
BKM-220D
Optional
BKM-243HS
Optional
BKM-255DV
INPUT
MONITOR OUT
BKM-220D
DIGITAL
1
2
INPUT
MONITOR OUT
1
2
BKM-243HS
DIGITAL/HD SDI
BKM-255DV
DV IN/OUT
1
2
MEU-WX2
Front Panel
Rear Panel
SD-SDI Input
(BNC x 2)
SD-SDI Monitor Output
(BNC x 1)
HD-SDI/SD-SDI
Monitor Output (BNC x 1)
DV Input/Output (6-pin IEEE1394 x 2)
HD-SDI/SD-SDI
Input (BNC x 2)
BKM-220D Connector Panel
BKM-243HS Connector Panel
BKM-255DV Connector Panel
* SXGA and WXGA images are down-converted for display.
P01
VGA mode 3
31.469
59.940
25.175
Negative
Negative
P02
640 x 480
VGA VESA 75 Hz
37.500
75.000
31.500
Negative
Negative
P03
VGA VESA 85 Hz
43.269
85.008
36.000
Negative
Negative
P04 VGA
(non-CRT)
29.531
59.780
23.625
Positive
Negative
P05
SVGA VESA 60 Hz
37.879
60.317
40.000
Positive
Positive
P06
800 x 600
SVGA VESA 75 Hz
46.875
75.000
49.500
Positive
Positive
P07
SVGA VESA 85 Hz
53.674
85.061
56.250
Positive
Positive
P08 SVGA
(non-CRT)
36.979
59.837
35.500
Positive
Negative
P09
XGA VESA 60 Hz
48.363
60.004
65.000
Negative
Negative
P10 1024 x 768
XGA VESA 75 Hz
60.023
75.029
78.750
Positive
Positive
P11
XGA VESA 85 Hz
68.677
84.997
94.500
Positive
Positive
P12
1280 x 768
WXGA* (CRT 60 Hz)
47.693
59.992
80.125
Negative
Positive
P13 WXGA*
(non-CRT)
47.396
59.995
68.250
Positive
Negative
P14
1280 x 1024
SXGA* VESA 60 Hz
63.981
60.020
108.000
Positive
Positive
P15 SXGA*(non-CRT)
63.194
59.957
91.000
Positive
Negative
P16
720 x 400
VGA TEXT
31.469
70.087
28.322
Negative
Positive
P17
1024 x 768
VGA (non-CRT)
47.297
59.870
56.000
Positive
Negative
P18
1280 x 768
WXGA* (CRT 75 Hz)
60.091
74.926
102.875
Negative
Positive
P19
1280 x 800
WXGA
48.935
59.969
68.900
Negative
Negative
Vertical
Horizontal
No.
Preset Signal
fH [kHz]
fV [Hz]
Dot Clock
[MHz]
Sync. polarity
