4-15 Integration Scaling Matrix Switcher • Programmer’s Guide
Command/response table for special function SIS commands (cont’d)
Command ASCII Command Response Additional description
(host to switcher) (switcher to host)
Blue screen
Blue screen (blue & sync output only) X19 *8# 1Blu X19 X19 :Output 1/2 Output 1/2
00 = Off/Off 02 = Off/On
01 = On/Off 03 = On/On
Example: 1*8# 1Blu1 Blue and sync output for setup.
Read blue screen 8# X19
Edge smoothing
Edge smoothing X19 *16# 1Fil X19 X19 :Output 1/2 Output 1/2
00 = Off/Off 02 = Off/On
01 = On/Off 03 = On/On
Example: 1*16# 1Fil01 Enable edge smoothing.
Read edge smoothing 16# X19
Enhanced mode
Enhanced mode X19 *12# 1Enh X19 X19 :Output 1/2 Output 1/2
00 = Off/Off 02 = Off/On
01 = On/Off 03 = On/On
Example: 1*12# 1Enh01 Enable enhanced mode.
Read enhanced mode 12# X19
Auto Image
Set Auto Image X3 *13# Img X3 0 = off, 1 = on.
Example: 1*13# Img001 Set Auto Image to on .
Execute Auto Image X19 *14# Img X19 X19 : Auto Image input tied to
output:
Output 1/2
Output 1/2
01 = Yes/No 03 = Yes/Yes
02 = No/Yes
X2 Reconfig Output X2 Auto Image is
complete.
X2 Reconfig Output X2 Auto Image is
complete.
If Auto Image adjustments are not necessary for an input, the X2 Reconfig message may not be
received.
Read auto image 14# X19
PAL film mode
Set PAL film mode X1 * X3 *18# X1 Flm X3 X3 : 0 = off, 1 = on.
Example: 8*1*18# 8Flm01 The ISM uses its 2:2 pulldown
(PAL) video processing
algorithms to scale input 8.
Read PAL film mode X1 *18# X3 X3 : 0 = off, 1 = on.
