3-15 Integration Scaling Matrix Switcher • Operation
User presets are recalled using the Input buttons. See “Recalling a user preset”,
earlier in this chapter, for instructions on recalling a user preset.
Erase Preset submenu
Select the output with the settings that you want to erase by pressing the desired
Output button.
Rotate either the Adjust or the Adjust knob while the Erase Presets submenu is
active to highlight (< >) one of three memory presets to erase or highlight N/A for
no preset. Press the Next button to erase the preset. Highlight N/A and press the
Next button to exit without erasing the settings.
Exit menu
From the Exit menu (figure 3-12), press the Next button to return to the default
display cycle, or press the Menu button to return to the Video & Audio
Configuration menu
Menu
Next
Menu
Default
Cycle
Video & Audio
Configuration
Exit Menu
Press Next to Exit
User Presets
Figure 3-12 — Exit menu flowchart
