B-5 Integration Scaling Matrix Switcher • Reference Information
Cables and connectors
When using signals with a scanning frequency of 15-125 kHz and running
distances of 100 feet or more, use high resolution BNC cables to achieve
maximum performance.
Bulk cable
Extron Part Part #
RG6/super high resolution cable
RG6 bulk , 500' (150m), single conductor 22-098-02
RG6-1 bulk , 1000' (300m), single conductor 22-098-03
RG6-5 bulk , 500' (150m), five conductor 22-100-02
MHR-5 Cable (Non-plenum)
MHR-5 bulk, 500' (150m) 22-020-02
MHR-5 bulk, 1000' (300m) 22-020-03
MHR-5p (Plenum) Cable
MHR-5P bulk, 500' (150m) 22-103-02
MHR-5P bulk, 1000' (300m) 22-103-03
Assorted connectors
BNC connectors
BNC male, mini HR crimp connectors, qty. 50 100-250-01
BNC male RG6 crimp connectors, qty. 50 100-260-01
BNC bulkhead connectors, qty. 50 (for custom wall plates) 100-076-51
Pre-cut cables
MHR-5 cable is used for RGBHV cable runs. It can also be used for composite
video, S-video, or RGsB. All Extron BNC cables have male connectors on both
ends. A plenum version of the MHR cable is also available.
MHR-5 Cable
MHR-5 BNC (6' /1.8 meters to 300' /90.0 meters) 26-260-xx
Bulk cable in lengths up to 5000' (1524 meter) rolls is available with or
without connectors.
Button Labels
Eight sets of button labels are provided on the next page. If desired, cut them out
of the manual, write the applicable button information in each button area, and
place them in the switcher’s label window.
