4. OPERATION
fig.1
fig.2
Control Panel
2. INTRODUCTION
Powerful dehumidification capacity. Removes excess moisture from air, preventing build-up of
mildew and mould. Features auto-defrost function, which activates if the room temperature falls
too low. Washable activated carbon air filter. Refrigerant is R407C. May be connected to a drain
hose for continuous operation. mounted on castors for manoeuvrability.
3. SPECIFICATION
 When using continuous draining, make sure that the drain hose is positioned correctly.
 ensure that heating appliances are not exposed to the flow of air from the dehumidifier.
 Before attempting to move the dehumidifier, empty the contents of the collection tank.
 switch off and disconnect it from the mains before attempting any cleaning or other maintenance work.
 ensure that the dehumidifier is correctly turned off when not in use, and stored in a safe, dry area, out of reach of children.
 WARNING! The warnings, cautions and instructions in this manual cannot cover all possible conditions and situations that
may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into
this product, but must be applied by the operator.
NOTE: This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
Air from the room is drawn through the dehumidifier by a fan, this air is filtered capturing airborn dust. moisture in the air condenses on
the cooling coils falling as droplets into a drip tray and internal or external water tank. efficiency of the dehumidifier is influenced by the
air outside the room. For operating efficiently, avoid opening and closing the windows and doors. For best performance, operate the
dehumidifier within the usable operating temperature.
4.1. Operation
4.1.1. Plug the unit in to the mains socket, a beep will be heard when inserting the plug.
4.1.2. Press the "on/oFF" switch and the operation light will illuminate, the humidity display will light to display the previous set humidity. the
initial setting for humidity is 60%, after 3 seconds the display will show the current humidity.
4.1.3. Press the humidity up or down buttons to adjust to the desired humidity required. If the required humidity is 3% below the current
humidity the unit will start automatically, if the set humidity is 3% more than the current humidity the dehumidifier will automatically stop.
4.1.4. the unit has a memory function. use the humidity up and down buttons to adjust to the desired setting and then press the memory
button to record the setting, each time the machine is switched on it will automatically run at the required setting.
4.1.5. When setting the humidity to less than 30%, the unit will run continuously and the display will read "co".
4.1.6. to shut the dehumidifier down press the "on/oFF" switch.
Note: If the humidity setting is greater than the current humidity the unit will not run.

WARNING! the fan motor and compressor must run for at least 3 minutes while dehumidifying.
 DO NOT start the dehumidifier immediately after shutting down, allow 3 minutes before restarting.
sdH70 Issue: 1 - 26/11/14
Original Language Version © Jack sealey limited
Model No:...............................................................................SDH70
supply:....................................................................................... 230V
Power:..................................................................................... 1360W
dehumidifier capacity:......................................................... 70ltr/day
maximum Airflow:................................................................. 800m³/hr
refrigerant:.............................................................................. r407c
condensate tank:........................................ 5.8ltr (with auto shut off)
Working temperature range:.............................................. 5° - 32°c
dimensions (l x W x H):..................................... 497 x 420 x 850mm
Weight:........................................................................................ 44kg
