22 • CRT Monitor Mounting Solutions Orderguide • rev. 05/13/04 870-03-018
Appendix
Fixed Arms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 lbs (45.4 kg)
6" Suspension Arms
6" x 13" “A” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15–35 lbs (6.8–15.9 kg)
6" x 13" “B” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35–65 lbs (15.9–29.5 kg)
6" x 19" “A” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15–35 lbs (6.8–15.9 kg)
6" x 19" “B” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35–65 lbs (15.9–29.5 kg)
6" x 19" “C” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65–100 lbs (29.5–45.4 kg)
10" Lift Arm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20–60 lbs (9.1–27.2 kg)
12" Suspension Arm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25–100 lbs (11.4–45.4 kg)
16" Lift & Suspension Arms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25–100 lbs (11.4–45.4 kg)
N12 Suspension Arm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25–100 lbs (11.4–45.4 kg)
Extender Arms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Varies by arm, see table
Keyboard Holders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 lbs (6.8 kg)
CPU Holders
Vertical, Small . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 lbs (22.7 kg)
Vertical, Medium . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 lbs (45.4 kg)
Vertical, Large . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 lbs (68.1 kg)
Horizontal, Medium . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 lbs (45.4 kg)
Horizontal, Large . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 lbs (68.1 kg)
CPU Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125 lbs (56.7 kg)
Footrest
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 lbs (90.8 kg)
Peripheral Table, Fold-Away Underbracing . . . . . . . . . . . . . . . . . . . . . . . . . 50 lbs (22.7 kg)
Peripheral Table, Fixed Underbracing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 lbs (45.4 kg)
Weight Capacity
Weight Capacity of
Extender Arms
Extender
Arm Length
12"
18"
24"
30"
Wall Track
Capacity
65 lbs (29.5 kg)
80 lbs (36.3 kg)
60 lbs (27.2 kg)
75 lbs (34.0 kg)
70 lbs (31.8 kg)
70 lbs (31.8 kg)
65 lbs (29.5 kg)
70 lbs (31.8 kg)
60 lbs (27.2 kg)
65 lbs (29.5 kg)
60 lbs (27.2 kg)
60 lbs (27.2 kg)
65 lbs (29.5 kg)
60 lbs (27.2 kg)
60 lbs (27.2 kg)
55 lbs (25.0 kg)
50 lbs (22.7 kg)
50 lbs (22.7 kg)
60 lbs (27.2 kg)
50 lbs (22.7 kg)
50 lbs (22.7 kg)
45 lbs (20.4 kg)
40 lbs (18.2 kg)
40 lbs (18.2 kg)
Wall Bracket
Capacity
65 lbs (29.5 kg)
100 lbs (45.4 kg)
60 lbs (27.2 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
65 lbs (29.5 kg)
100 lbs (45.4 kg)
60 lbs (27.2 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
65 lbs (29.5 kg)
100 lbs (45.4 kg)
60 lbs (27.2 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
65 lbs (29.5 kg)
100 lbs (45.4 kg)
60 lbs (27.2 kg)
95 lbs (43.1 kg)
90 lbs (40.9 kg)
90 lbs (40.9 kg)
Command Post
Capacity
65 lbs (29.5 kg)
100 lbs (45.4 kg)
60 lbs (27.2 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
65 lbs (29.5 kg)
100 lbs (45.4 kg)
60 lbs (27.2 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
65 lbs (29.5 kg)
100 lbs (45.4 kg)
60 lbs (27.2 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
100 lbs (45.4 kg)
65 lbs (29.5 kg)
100 lbs (45.4 kg)
60 lbs (27.2 kg)
95 lbs (43.1 kg)
90 lbs (40.9 kg)
90 lbs (40.9 kg)
Suspension
Arm Model
6"V x 13"L
6"V x 19"L
10" Lift
12"V
16" Lift & Susp.
N12
6"V x 13"L
6"V x 19"L
10" Lift
12"V
16" Lift & Susp.
N12
6"V x 13"L
6"V x 19"L
10" Lift
12"V
16" Lift & Susp.
N12
6"V x 13"L
6"V x 19"L
10" Lift
12"V
16" Lift & Susp.
N12
