Handling and operation
9 UPA 500 A1
GB
Operation
The appliance has three operating modes:
Standby
The appliance switches automatically into standby mode (energy
saving mode) if no movement has occurred within the monitoring
area for about 30 seconds. In the case of movement occuring, the
appliance automatically detects the entrance or exit, and switches
itself on again.
Entrance
On entrance into the garage the appliance switches itself on with the
light sequence green - yellow - red.
Exit
Should a vehicle remove itself from close to the appliance, the yellow
LED
4 switches on and then the green LED 5 .
Switch the appliance on by sliding the on/off switch ♦ 2 to the
position "ON". The LEDs fl ash briefl y (red, yellow, green).
The appliance is now operational and the green LED
5 glows
permanently.
Now test the functionality by moving slowly towards the ultra- ♦
sonic sensor 7 and checking the individual light signals of the
Parking Lamp .
Light signal Distance from ultrasonic sensor
green approx. 5 - 1.5 m
yellow approx. 1.5 - 0.5 m
red approx. 0.5 - 0 m
