Se8245, Se8235, Sm8263 – Eclipse - Fujitsu Ten AV8533 User Manual
Page 51: Se8465a, Se8465e, Se8365, Marine loudspeaker
51
SE8245
4˝ 2-Way
• Continuous Power Handling: 25W
• Music Power Handling: 75W
SE8235
3-1/2˝ 2-Way
• Continuous Power Handling: 20W
• Music Power Handling: 60W
SM8263
Marine Loudspeaker
Waterproof full-range speaker
Sensitivity
85dB
Woofer Cone
6-1/2˝
(UV Solar-Protected)
Tweeter
20mm Aluminum Hard Dome
(UV Solar-Protected)
Basket
Oen Piece Cast Powder Coated
Aluminum
Grille
Polycarbonite Plastic
(UV Solar-Protected )
Woofer Magnet
Ferrite
Tweeter Magnet
Neodymium
Mounting Depth
3-1/2˝
ECLIPSE introduces a high-performance speaker
that is impervious to the elements and
specifically designed for excellent response in an
open-air environment such
as on a boat.
Marine Loudspeaker
SE8465A
4
×
6˝ 2-Way
• Continuous Power Handling: 30W
• Music Power Handling: 90W
SE8465E
4
×
6˝ 2-Way
• Continuous Power Handling: 30W
• Music Power Handling: 90W
SE8365
6-1/2˝ 3-Way
• Continuous Power Handling: 40W
• Music Power Handling: 120W
SE8465E
SE8365
SE8355
SE8405
SE8245
SE8235
4
×
6˝ 2-Way
6-1/2˝ 3-Way
5-1/2˝ 3-Way
4
×
10˝ 3-Way
4˝ 2-Way
3-1/2˝ 2-Way
105 — 40,000Hz
90 — 40,000Hz
90 — 40,000Hz
65 — 40,000Hz
105 — 40,000Hz
120 — 40,000Hz
87dB
90dB
89dB
91dB
89dB
87dB
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
—
—
—
●
—
—
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
1-3/4˝
1-7/8˝
1-7/8˝
2-3/8˝
1-5/8˝
1-1/2˝
