Subwoofers
SYSTEMS
46
SW6124BXD
12˝ × 2 Subwoofer System
SW6104BXD
10˝ × 2 Subwoofer System
SW6124BX
12˝ Subwoofer System
SW6104BX
10˝ Subwoofer System
Available in several configurations to optimally
match user vehicles from trucks and SUVs to
cars, these subwoofer systems are constructed
from sturdy wood, carefully assembled and
well-damped for a tight bass. Finished in
attractive and durable vinyl, these subwoofer
systems are ready for final installation. ECLIPSE
subwoofer systems add a new dimension to the
sound, providing a solid foundation for a
dynamic full bandwidth sound system.
SW5124BX
12˝ Truck-box Subwoofer System
Cutaway view of the SW5124 Lo-Profile Custom
Application Woofer shows the significantly reduced
depth of this speaker that makes it an ideal choice to
install in a truck-box enclosure.
Featuring a configuration specifically designed for
the installation space requirements of trucks, SUVs
and similar vehicles, the SW5124BX incorporates a
special low-profile bass driver that saves space and
still delivers a massive low frequency sound.
• Continuous power handling: 125W
• Maximum power handling: 250W
• Continuous power handling: 500W/400W
• Maximum power handling: 1000W/800W • Continuous power handling: 250W/200W
• Maximum power handling: 500W/400W
Speaker Grill Speaker Grill
SW6124BXD SW6104BXD SW6124BX SW6104BX SW5124BX SW6102.4BX
Subwoofer Driver SW6124 × 2 SW6104 × 2 SW6124 SW6104 SW5124 SW6102.4
Frequency Response 28 — 250Hz 35 — 250Hz 28 — 250Hz 35 — 250Hz 35 — 250Hz 30 — 150Hz
Sensitivity 1W/m SPL 88dB 86dB 85dB 83dB 88dB 88dB
Normal Impedance 8 Ω + 8 Ω Parallel 8 Ω + 8 Ω Parallel 4 Ω 4 Ω 4 Ω 4 Ω
Dimensions (W × H × D) 27.6˝ Ч 13.8˝ Ч 15.3˝ 23.6˝ Ч 12.7˝ Ч 15.3˝ 14.7˝ Ч 13.9˝ Ч 15.3˝ 13.5˝ Ч 12.7˝ Ч 15.3˝ 18.9˝ Ч 15˝ Ч 8˝ 22˝ Ч 12.6˝ Ч 15.3˝
701 Ч 350 Ч 389mm 600 Ч 323 Ч 389mm 373 Ч 353 Ч 389mm 343 Ч 323 Ч 389mm 480 Ч 381 Ч 203mm 701 Ч 350 Ч 389mm
Weight (Gross) 51.8lbs (23.5kg) 46.8lbs (21.3kg) 30.8lbs (14kg) 21.2lbs (9.6kg) 26lbs (11.8kg) 40lbs (18.2kg)
Weight (Net) 51.3lbs (23.3kg) 46.4lbs (21kg) 30.5lbs (13.9kg) 20.9lbs (9.6kg) 25.5lbs (11.6kg) 36.1lbs (16.4kg)
Finish Grey & Black Vinyl Grey & Black Vinyl Grey & Black Vinyl Grey & Black Vinyl Grey & Black Vinyl Vehicle grade gray carpet.
Continuous Power Handling 500W 400W 250W 200W 125W 200W
Maximum Power Handling 1000W 800W 500W 400W 250W 300W
SW6102.4BX
10˝ “Bass” Bandpass Subwoofer
• Continuous power handling: 200W
• Maximum power handling: 300W
