SW4200/SW4000 Kevlar Composite Cone Series
45
•Kevlar composite cone
•Integrated grill assembly
•Stamped basket
•Foam surround
•Polycarbonate spider
•Magnet (SW4000:30oz, SW4200:43oz)
•4-layer aluminum single voice coil
•Air vent cooling system
•Screw type terminals
The new SW4000 Series of subwoofers offer an
extraordinary performance for an entry-level
series. ECLIPSE engineers were able to achieve
a performance level comparable to subwoofers
in a higher class. Through tests and listening
evaluations, it was determined that a proprietary
Kevlar composite cone material would provide
an ideal solution with extended low frequency
response, pitch definition and transient
response. Featuring a distinctive and attractive
grill design, the SW4000 Series is available in
the two most popular subwoofer sizes.
SW4200
12˝ Subwoofer (4 Ω )
SW4000
10˝ Subwoofer (4 Ω )
• Continuous power handling: 250W
• Maximum power handling: 750W • Continuous power handling: 200W
• Maximum power handling: 600W
SW4200 SW4000
Size 12” 10”
Fs 32Hz 38Hz
Qts 0.56 0.60
DCR 3.6 Ω 3.6 Ω
Vas 2.75 Cuft 1.25 Cuft
Xmax (one way) 0.27˝ 0.27˝
Continuous Power Handling 250W 200W
Maximum Power Handling 750W 600W
A new approach for a dynamic subwoofer solution.
Side view of SW4200 series.
750W 600W
