Introduction
Toilet Seat
Introduction
Please familiarise yourself with the product
prior to assembly. Carefully read the
following assembly instructions and safety
tips. Only use the unit as described and for the
specified applications. Store these instructions in
a safe place. If passing this product on to a third
party also include all documents.
Intended use
This toilet seat is intended for installation on standard
commercially available toilets. Any use other than
the aforementioned or any product modification is
prohibited and can lead to injuries and / or product
damage. The manufacturer is not liable for any
damages caused by any use other than its intended
purpose. This product is not intended for commercial
use.
Description of parts
and features
1
Hinge with threaded rod
2
Sealing cone washer
3
Metal washer
4
Plastic washer
5
Plastic nut
6
Metal nut
7
Wings for nut (tightening aid)
8
Toilet seat
9
Silicone cap
10
Battery box
11
Pile and loop fastening strip
12
Plug
13
ON / OFF switch
Supply Scope
Please check immediately on unpacking that the
delivery is complete and that the product and all
parts are in perfect condition. Do not under any
circumstances assemble the product if the delivery
is incomplete.
2 Hinges with threaded rod
2 Sealing cone washers
2 Metal washers
2 Plastic washers
2 Plastic nuts
2 Metal nuts
1 Wings for nut
1 Toilet seat
1 Silicone cap
1 Battery box
1 Pile and loop fastening strip
2 1.5 V
AA batteries (Model Z30397A)
3 1.5 V
AA batteries (Model Z30397B)
1 Assembly instructions
Technical data
Dimensions:
approx. 36 x 5.5 x 42 cm
(W x H x D)
Operating voltage: 3 V (Model Z30397A)
4.5 V (Model Z30397B)
Battery:
2 x 1.5 V
, AA
(Model Z30397A)
3 x 1.5 V
, AA
(Model Z30397B)
LED:
10
x 0.03 A (Model Z30397A)
10 x 0.03 A (Model Z30397B)
Protection class:
IP44 (spray water protected)
Maximum
load capacity:
150 kg
Model Z30397A: red LEDs
Model Z30397B: blue LEDs
Material
Toilet seat:
Polyresin
Hinges: Stainless
steel
