NEW EPSON ActionPC 5000, ActionTower 5000
SETUP Stored in ROM; accessible by pressing F2
Program during boot
System security User and Supervisor level passwords
(8 characters) available for system boot or
diskette
access
Virus protection Write protection feature for the
hard
disk
drive boot sector; periodic reminder
message for running virus detection utility
Physical Characteristics
Dimension
Width
Depth
Height ActionPC
16.8 inches (427 mm)
15.8 inches (401 mm)
4.4 inches (112 mm)
ActionTower
7.125 inches (181 mm)
16.25 inches (413 mm)
13.25 inches (337 mm)
Weight
*
17.4 pounds (7.9 kg)*
With one diskette drive, without keyboard
16.7 pounds (7.6 kg)*
Power Supply
Type 200 Watt, UL/TUV/CSA listed, fan-cooled
Input ranges 90-130 VAC or 180-260 VAC;
switch-selectable
Maximum +5 VDC at 20 Amps, -5 VDC at 0.5 Amps
outputs +12 VDC at 8 Amps, -12 VDC at 0.5 Amps
Frequency 47 to 63Hz
Cables Two to main system board, five to mass
storage devices; for more than five
devices, Y cables can be installed on the
existing cables
Option slot power limits
Output Voltage (MC) I +5 Volts -5 volts +12 volts -12 votts
For all slots I A m p s
Environmental Requirements
Condition
Temperature
Non-operating
Operating range range Storage range
41° to 90°F -4° to 140°F -4° to 140°F
(5° to 32° C) (-20° to 60° C) (-20° to 60° C)
Humidity I 20% to 90% I 10% to 90% 10% to 90% I
(non-condensing)
Altitude
Maximum wet bulb
Major Subassemblies
The following diagrams illustrate the major subassemblies in
the ActionPC 5000 and ActionTower 5000 systems.
ActionPC
option card SIMM power
connector sockets supply
board
sockets
tag RAM
external
cache
- H
sockets
*
VESA
J r -
connector
microprocessor
drive
mounting drive bays
bracket
ActionTower
external
cache sockets
\
video
memory
s o c k e t s
drive bays
SIMM sockets
power
supply
8/94 NEW EPSON ActionPC 5000, ActionTower 5000 - 3
