10
GB
Overview
A 1 Safety blade
2 Gearbox
3 Lubrication port
4 Stop lever fixing
5a Stop lever
5b Safety lever
6 Handle for adjusting the blade
beam
7 Front arm
8 Safety button
9 Pivotal centre
10 Round handle
11 Safety slide
12 Deadman switch
13 On/off switch
14 Mains cable
15 Shoulder strap
16 Eye (for shoulder strap)
17 Leg protection
18 Blade protection
Scope of delivery
- Long-handled hedge trimmer (two-part)
- Blade protection
- Leg protection
- Shoulder strap
- Instruction Manual
Assembling the
Long-Handled Hedge
Trimmer
Pull out the power plug before car-
rying out any work on the equip-
ment.
Use only original parts.
B 1. Unpack the device and check it
for completeness.
2. Slide the front arm (7) of the
long-handled hedge trimmer
onto the tubular shaft of the
long-handled hedge trimmer
and turn slightly. The safety but-
ton (8) then locks into place. Fix
the two shaft elements to the
star wheel (9). Screw the nut
onto this from the threaded rod
on the star wheel (9) and place
it sideways in the holder on
the tubular shaft. With the star
wheel, push the threaded rod
(9) through the tubular shaft and
screw the star wheel (9) together
with the nut.
C 3. Assemble the leg protection for
right-handed users in variant a).
For left-handed users, assemble
the leg protection rotated in
variant b) as per the illustration.
Insert the square nuts (19) into
the leg protection (17). Place the
leg protection on the assembly
block (22) in position a) or b) as
desired. Push the screws (21)
through the aligning holes and
screw the leg protection onto the
assembly block until it is sitting
firmly.
Operating the Hedge
Trimmer
Do not use the equipment with-
out the hand guard. Wear suit-
able clothing and work gloves
when working with the equip-
ment.
Ensure that the equipment is
functional before each use. The
