5. Attach the Speed Switch to the wall outlet box and secure with the two
screws provided. (Fig 4)
6. Attach the wall plate to the switch with the two screws provided. (Fig. 4)
NOTE: If your fan has the original pull chain speed control, you
MUST set and leave this control on High Speed.
Fig. 4
Fig. 5
2
Wall plate
Switch
Outlet box
Screws
Screws
Restore power to the ceiling fan and test for proper operation.
Speed Slide Switch: The Slider is used to set each fan speed
separately. Move it up or down to select the desired speed.
1= High Speed
2 = Medium High Speed
3 = Medium Speed
4 = Low Speed
= Fan Off
OPERATING YOUR WALL CONTROL
If the switch does not work correctly, check the following.
● Check the main power supply and make sure the circuit is
powered ON.
● Make sure the Manual Speed Pull Chain is set on HIGH SPEED.
TROUBLESHOOTING GUIDE
