Introduction 1-1
1
Introduction
This chapter introduces the C1H124-48 and C1G124-24 standalone Ethernet switch devices.
1.1 OVERVIEW
The following provides an overview of the C1H124-48 and C1G124-24.
C1H124-48
The C1H124-48 ( Figure 1-1 ) has several types of port connections, which include
• forty-eight front panel RJ45 ports (10BASE-T/100BASE-TX compliant),
• two front panel RJ45 ports (1000BASE-T compliant), and
• two expansion slots for optional Mini-GBIC interface modules.
The 10/100 Mbps fixed front panel ports can operate in either half-duplex or full-duplex mode, as
determined by Auto-Negotiation.
A single LED is provided for each port to indicate link status and activity. The LED is lit when there
is a link, and flashes when there is traffic.
Important Notice
Depending on the firmware version used in the device, some features described in this document
may not be supported. Refer to the Release Notes shipped with the device to determine which
features are supported.
